Designed for measurement of small caliber and low-speed medium
With reliable performance, few maintenance and long service life
Low requirement for the straight tube section
Widely measure ratio: 10:1
Dual-line display, instantaneous/ cumulative flow rates displayed at the field
With a keyboard on the indictor for convenient operation and setting
All in metal construction, designed for measuring corrosive medium of high temperature, high pressure and strong Non-contact magnetic coupling transmission
Applicable for inflammable and explosive occasion
Optional charging modes: DC power supply or battery power
With the functions of data recovery, data backup and power failure protection
Multiple parameters calibrating function
petrochemical engineering
iron and steel
electric power
metallurgy
light industry
food
pharmacy
water treatment
Connection of flow meter: DN15，DN25，DN50，DN80，DN100，DN150
Range of flow:Liquid： 1.0～150000l/h Gas：0.05～3000m3/h
Measure Ratio: 10∶1，20∶1（special）
Precision: Grade 0.5, Grade 1.0 (special)
Pressure rating: DN15、DN25、DN50：4.0MPa（Max: 20MPa） DN80、DN100、DN150：1.6MPa （DN80：Max 10MPa, DN100：Max 6.4MPa, DN150：Max 4.0MPa）
Medium temperature:Standard：-30℃～+120℃，high temperature：120℃～350℃
Power supply: 24VDC（12～36VDC）
Output signal: 4～ 20mADC (two-wire configuration); attached HART Protocol allowed
Output load: 500Ω（24V power supply）
Environmental temperature:Local type：-40℃～120℃ Remote-control type：-30℃～60℃
Storage requirement:Temperature：-40℃～85℃ humidity：≤85%
Connection mode: Flange connecting. Flange standard ：GB/T9119-2000; User’s appointment allowed
Cable interface: M20×1.5
Housing protection grade:IP65
Mark of explosion-proof:Intrinsic safety type：ExiaIICT6，explosion-proof type：ExdIICT6
Pressure loss: See table of flow for detailed information
Viscosity of medium: DN15：η＜5mPa.s DN25：η＜250mPa.s DN50～DN150：η＜300mPa.s
