Why-Winters
1 LRD707 has a large bandwidth, so it has a high range resolution.
2 The radar transmitter and the receiver can work at the same time, and there is no distance blind area.
3 Under the same detection capability, LRD707 has low transmitting power and is not easy to be intercepted.
4 the whole system of LRD707 has a simple structure, small size, light weight and low cost.
The measuring equipment is used for continuous non-contact level measurement of liquids, slurries and slurries.
Radar frequency: 120GHz
Equivalent omnidirectional radiated power: <10uW
Measuring range: 0.01~30m
Power consumption: <2.4W
Power supply: 24VDC two-wire; 24VDC, 220VAC, four-wire
Display resolution: 0.1mm
Measurement accuracy: ±1mm
Output: 4~20mA
Communication type: RS485, HART
Process pressure: 0~2.5MPa, the maximum pressure of the special isolation device can reach 10MPa
Ambient temperature: -40~+80℃
Process temperature: -40~+200℃, through the special heat insulation device temperature can reach 680℃
Case material: cast aluminum
Protection level: IP67
