Accuracy：0.075% or 0.05%URL

display：LC display（option）

output signal：4-20mA 2wire/V=10.5-55Vdc

               4-20mA+HART 2wire/V=16.5-55Vdc

               15V 32wire/V=10.5-55Vdc

               MODBUS 4wire/V=9-30Vdc

long term stability：≤0.2% per 5 years

thermal drift：±（0.1+0.1TD）%SPAN/℃

static pressure effect：±0.2%SPAN/10MPa

mounting position effect：max 400pa，can be calibrated by zero set on site

ingress protection：IP66/67

process connection：1/4"NPT female，other with adapter

housing：rugged die-cast aluminumpainted blue

diaphragm material：316L(standard)，option：HaC-276,tantalum or 316L gold plating

socket and flange：316

O-ring：PTFE

sensor fill fluid：silicon oil，option：fluorolube，high temperature oil

explosion proof：CSA,NEPSI,Exd IIC T6 Gb
