sensor type：    Silicone piezoresistive

pressure range：0-0.1bar...0-60bar (include vacuum)

accuracy：        0.5%FS or 0.25%FS

response time：10mS, typical   30mS , max

pressure resistance：1.5 times of FS (over pressure)  2 times of FS (burst pressure)

ambient temperature：-40...85°C

media temperature：  -40...80°C

compensate temperature：-10...70°C

storage temperature：-40...85 °C

ingress protection：IP65 or IP67 EN60529

output signal：    4-20mA, 0-10V, 1-5V

supply voltage：    12-30VDC

load resistance：   RL≤500Ω（current output） RL＞100 kΩ（voltage output）

long term stability：Max 0.15%FS/year

housing material：304SS

Socket and thread：304SS or 316SS

Sensor diaphragm：316LSS

Cable connection：M12*1, 4-pin  DIN43650
