Measuring media:    Dry and non-corrosive gas

Measuring range:     -30/30Pa to -5/5kPa

Measuring accuracy:2%FS(FS≤100Pa) , 1%FS(FS＞100Pa)

Overpressure:          7kPa(FS≤1kPa), 5 times of FS(FS＞1kPa)

Long term stability:  max 0.25% per year

Output signal:          4-20mA or RS485

Supply voltage:        12-28Vdc

Response time:        0.5S

Housing material:     ABS

Ambient temperature:-40-80℃

Ambient humidity:   5-90%RH (non-condensation)

Compensated temperature:-10-60℃

Ingress protection:   IP 65 EN60529

Electrical connection:Cable gland (4-8mm cable diameter)
