Temperature sensor：    Pt100 or Pt1000

Sensor accuracy：         Class B ±（0.3+0.005*t）℃

                                   Class A ±（0.15+0.002*t）℃

                                   Class 1/3B ±1/3*（0.3+0.005*t）℃

Sensor quantity：          single or dual

Conncetion wire：          2-wire, 3-wire or 4-wire

Output singal：             Pt100, Pt1000 or 4-20mA(with transmitter)

Stem diameter D：        6mm

Stem length EL：           from 50mm to 1000mm

Stem material：            316SS or 316LSS

Process connection：     G1/2”, M20*1.5, 1/2”NPT

Neck diameter M：        14mm

Digital display：            Please refer our TTID data

Cable head：                Pleare refer the cable head data

Explosion proof：          Exd IICT6(norminal), Exia IICT6(available)

Temperature transmitter：RTD input: TTIR

                                      Universal input: TTIS

                                      with HART protocol: TTHA

IP protection：                 IP65 or IP67（Depends on cable head）
